Features:
.Design & Manufacture: Q/JBGN02, GB 12239-89
.Face to Face Dimension: Q/JBGN02, GB12221-89, QY 2000-2
.Flanged Dimension: JB78, GB4126, ANSI B16.5, DIN3202, JIS
.Inspect & Test: BS 6755, GB/T13927-92
.Operation: Handwheel, Pneumatic & Electric
.Size Ranges: 1” to 14”NB
.Pressure Rating: PN6, PN10, PN16, ANSI 125, ANSI 150.

Standard Materials Construction:
.Body/Bonnet: Cast Iron, Ductile Iron, Cast Steel, Stainless Steel and Duplex
.Sleeve: Rubber/NBR
.Stem: Cast Brass or Carbon Steel
.Bar: Carbon Steel
.Pressing Stem: Alum. Alloy
.Handwheel: Iron & Steel
.Bracket: Ductile Iron
