• Sizes 2 in. (50mm) through 40in. (1000mm)
• Pressure classes ASME/ANSI 150 through 2500
• Temperature ranges -20^o F to +350^o F (Standard Nace) and -50^o F to +250^o F (Low-temp Nace)
• NACE MR01-75 (Rev. 2002)and Low Temperature NACE MR01-75 (Rev. 2002) available
• Available with Raised Face or  Ring Joint flanged end connections
• Available with integral or replaceable seat
• Standard "through conduit" design allows for passage of pigs and spheres without any modifications
• Lifting eye bolts standard on sizes 4 in. (100mm) and larger valves
• Manufactured, tested and monogrammed in accordance with API 6D requirements
• All Valve nameplates marked with "CE" to indicate compliance with PED

COMPLIANCE TO SPECIFICATIONS

• API 6D
• ASME B16.34
• NACE Rev. 2002
• PED
• Fire tested to API 6FD
• TUV CE PED
• ISO 9001
