Features & Specifications
.Design & Manufacture: ANSI B16.34, BS 1873
.OS&Y Construction, Bolted Bonnet
.Full Port Or Reduced Bore
.Size Range: 2" to 48"N.B.
.Pressure Ratings: ANSI 150, 300, 600, 900
.End Connections: Flanged, Buttweld, Socket Weld, Hub Connectors, Compact Flange or other proprietary connections

.Materials Available in: WCB,LCB,CF8,CF8M,CF3,CF3M,WC6,WC9, C5,C12 or Equivalent, Available also in low temperature steels, low alloy steels, stainless steels, duplex type stainless steels and other exotic materials; Various trim materials available to suit service conditions

.Actuators: Manual, Electric, Hydrau-Pneumatic Actuator

.To MR 0175 and MR 103 upon Request
