Features & Specifications
.Design & Manufacture: API 602
.Constructions:OS&Y Construction, Bolted Bonnet, Welded Bonnet & Pressure Sealed Bonnet
.Back-seating, Renewable Seat Ring
.Full Port / Conventional Port
.Size Range: 1/4" to 4"N.B.
.Pressure Ratings: ANSI 800, 900, 1500 & 2500
.End Connections: Threaded, Flanged, Buttweld, Socket Weld, Hub Connectors, Compact Flange or other proprietary connections.

.Materials Available in: A105, F304,F316 or Equivalent, Available also in low temperature steels, low alloy steels, stainless steels, duplex type stainless steels and other exotic materials; Various trim materials available to suit service conditions

.Various trim materials are available to suit different service conditions

.Actuators: Manual

.To MR 0175 and MR 103 on request
